YVF2 Series Variable Frequency Speed Regulating Three-Phase Asynchronous Motor
YVF2 series variable frequency adjustable speed three-phase asynchronous motor is a new type of motor which is based on the newly designed Y2 series (IP54) motor. It has the advantages of novel structure, low noise and small vibration. The utility model has the advantages of wide speed regulation range and stable and stepless speed regulation. Good matching parameters and various frequency converter has, with vector control with fast dynamic response; low speed torque ripple, no resonance phenomenon; YVF2 series (IP54) three-phase asynchronous motor from 80~315 cited a total of 12 frame, 23 specifications, at present our factory development and production of 80~ 280 from a total of 11 motor frame size 19 specifications. According to JB/T7118-2004 "YVF2 series (IP54) variable frequency speed control three-phase asynchronous motor technical conditions," the relevant provisions of the design and manufacture. According to customer needs can also provide YVF2EJ series variable frequency speed regulation electromagnetic braking three-phase asynchronous motor.
Working Conditions:
(1) Altitude not exceeding 1000M
(2) Ambient air temperature shall not exceed 40 DEG C, not less than -15
(3) The monthly average humidity is not more than 90%, while the average monthly temperature is not higher than the temperature of 25 degrees C
(4) The working system is a continuous working system (S1)
(5) Using F class insulation
(6) Rated voltage is 380V
(7) The rated base frequency is 50Hz, usually for the 4 pole
(8) Ventilation cooling for IC416 (independent fan cooling)
